EN 10025 S275JR/S275J0/S275J2 HEB(IPB) BEAM
EN 10219 S235JRH MS Cold Formed Rectangular Tube Stockists in India, Carbon Steel S235JRH Rectangular Hollow Section Suppliers in Mumbai, Cold Formed EN 10219 S235JRH RHS Pipe.
When it comes to EN 10025 S275JR / S275J0 / S275J2 HEB (IPB) Beam, Hollow Section Profiles is one of the best manufacturers, suppliers, and exporters of EN 10025 S275JR HEB(IPB) Beams. These HEB (IEB) Beams possesses the best corrosion resistance properties. These EN 10025 S275J0 HEB (IPB) Beams are used in most of the construction projects. These EN 10025 S275J2 HEB (IPB) Beams are used in power plants, industrial sheds, warehouses, offshore structures. These EN 10025 S275JR HEB (IPB) Beams has been an ideal choice for construction projects as it provides high strength and it gets manufactured at very cheap rates comparing to other beams.
These EN 10025 S275JR0 HEB (IPB) Beams can carry weight at the time when wind or an earthquake occurs. These EN 10025 S275J2 HEB (IPB) Beams are very light in weightage. These EN 10025 S275JR HEB (IPB) Beams can carry vertical gravitational force as well as h. It has greater depth. The invention of EN 10025 S275J0 HEB (IPB) Beams has been proved one of the important innovations in the industry. This EN 10025 S275J2 HEB (IPB) Beam provides the required balance and stability to the construction.
At Hollow Section Profiles, These EN 10025 S275JR HEB (IPB) Beams are manufactured under the proper guidance and direction of industry experts. It provides longer durability. These HEB (IPB) Beams are produced in different patterns and shapes such as in circular shape or rectangular shape. At Hollow Section Profiles these EN 10025 S275J0 HEB (IPB) Beams are available in different dimensions starting from 100 mm to 220mm, customers can order these HEB (IPB) Beams as per their specifications. These EN 10025 S275J2 HEB (IPB) Beams can also be used in refineries, railway bridges, power plants, etc. EN 10025 S275JR HEB (IEB) Beams comes with a perfect finish, compact design, and high tensile strength.
Grade S235JRH Cold Formed Welded Structural Rectangular Hollow Section, EN 10219 S235JRH Seamless Cold Formed Rectangular Hollow Section Tubing, EN 10219 Cold Formed S235JRH ERW RHS Pipes Dealers in India.
Specification of EN 10025 S275JR/S275J0/S275J2 HEB(IPB) BEAM
| Size | 100mm x 100mm — 1000mm x 3000mm — |
| Wall Thickness | 0.5mm – 25mm |
| Length | 6000-14000 mm |
| Dimensional Tolerances | Thickness (All sizes +/- 10%) |
| Packing | In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark |
| Surface Protection | Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized |
Properties
S275JR GRADE
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Canada HG | European old EN | Italy UNI | Belgium NBN | Spain UNE | China GB | Sweden SS | Poland PN | Czechia CSN | Finland SFS | Austria ONORM | Norway NS | Russia GOST | Inter ISO | Portugal NP | India IS | |||||||||||||||||||||||||||||||
| S275JR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| C | Mn | P | S | N | Cu | CEV |
| max 0.22 | max 1.5 | max 0.04 | max 0.04 | max 0.012 | max 0.55 | max 0.42 |
S275JO GRADE
| EU EN | USA – | Germany DIN,WNr | France AFNOR | England BS | European old EN | Italy UNI | Belgium NBN | Spain UNE | China GB | Austria ONORM | Norway NS | Russia GOST | Inter ISO | Portugal NP | India IS | ||||||||||||||||||
| S275J0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| C | Mn | P | S | N | Cu | CEV |
| max 0.18 | max 1.5 | max 0.035 | max 0.035 | max 0.012 | max 0.55 | max 0.42 |
S275J2 GRADE
| EU EN | England BS | European old EN | Belgium NBN | China GB | Sweden SS | India IS | |||||||
| S275J2 |
|
|
|
|
|
|
| C | Mn | P | S | Cu | CEV |
| max 0.18 | max 1.5 | max 0.03 | max 0.03 | max 0.55 | max 0.42 |
size and weight
| Profile | Dimensions, mm | Weight | Section area | |||
| h | b | s | t | kg/m | cm2 | |
| HEB 100 | 100 | 100 | 6 | 10 | 20,4 | 26,0 |
| HEB 120 | 120 | 120 | 6,5 | 11 | 26,7 | 34,0 |
| HEB 140 | 140 | 140 | 7 | 12 | 33,7 | 43,0 |
| HEB 160 | 160 | 160 | 8 | 13 | 42,6 | 54,3 |
| HEB 180 | 180 | 180 | 8,5 | 14 | 51,2 | 65,3 |
| HEB 200 | 200 | 200 | 9 | 15 | 61,3 | 78,1 |
| HEB 220 | 220 | 220 | 9,5 | 16 | 71,5 | 91,0 |
| HEB 240 | 240 | 240 | 10 | 17 | 83,2 | 106 |
| HEB 260 | 260 | 260 | 10 | 17,5 | 93,0 | 118 |
| HEB 280 | 280 | 280 | 10,5 | 18 | 103 | 131 |
| HEB 300 | 300 | 300 | 11 | 19 | 117 | 149 |
| HEB 320 | 320 | 300 | 11,5 | 20,5 | 127 | 161 |
| HEB 340 | 340 | 300 | 12 | 21,5 | 134 | 171 |
| HEB 360 | 360 | 300 | 12,5 | 22,5 | 142 | 181 |
| HEB 400 | 400 | 300 | 13,5 | 24 | 155 | 198 |
| HEB 450 | 450 | 300 | 14 | 26 | 171 | 218 |
| HEB 500 | 500 | 300 | 14,5 | 28 | 187 | 239 |
| HEB 550 | 550 | 300 | 15 | 29 | 199 | 254 |
| HEB 600 | 600 | 300 | 15,5 | 30 | 212 | 270 |
| HEB 650 | 650 | 300 | 16 | 31 | 225 | 286 |
| HEB 700 | 700 | 300 | 17 | 32 | 241 | 306 |
| HEB 800 | 800 | 300 | 17,5 | 33 | 262 | 334 |
| HEB 900 | 900 | 300 | 18,5 | 35 | 291 | 371 |
| HEB 1000 | 1000 | 300 | 19 | 36 | 314 | 400 |
