STAINLESS STEEL A554 GR 316 RECTANGULAR HOLLOW SECTIONS

Stainless Steel Rectangular Hollow Sections

Hollow Section

Product

Stainless Steel A554 Gr 316 RHS Tubes, DIN 1.4401 / 1.4436 SS Rectangular Hollow Section Pipes, SS SUS 316 Rectangular Box Sections Exporters, AISI 316 Stainless Steel Rectangular Hollow Section Tube Distributors in Mumbai, India.

Hollow Section Profiles is one of the best manufacturers, suppliers, exporter, and stockiest of Stainless Steel A554 Gr 316 Rectangular Hollow Section based in Mumbai, India. These ASTM A554 Stainless Steel 316 Rectangular hollow sections possess the best corrosion resistance properties and provide long durability and long servicing life. Stainless Steel UNS S31600 Rectangular Hollow Section contains Ferrite content up to 68%, Chromium content up to 18%, and Nickel content up to 14%. It also contains 3% molybdenum content, 2% manganese content, 1% silicon content, and 0.08% carbon content.

Gr 316 Stainless Steel ASTM A554 Rectangular Hollow Sections are available as per the specific requirement of the client at a very effective price range. The size of these Rectangular hollow sections ranges from 10mm * 20mm to 150mm * 300mm, its available thickness size comes from 0.5mm to 6mm, while it has the length up to 6 meters. The melting point of 316 Stainless Steel Welded Rectangular Tube is at 2550 Degree F. It possesses high tensile strength up to 75000 Psi and yield strength up to 30000 Psi. Once these A554 Stainless Steel 316 Structural Rectangular Hollow Section gets manufactured, it passes through various tests such as mechanical tests, quality tests, material tests, chemical tests, PMI tests, micro tests, and macro tests, etc.

ASME SA554 Stainless Steel 316 ERW Rectangular Hollow Section has the best corrosion resistance to pitting and crevice corrosion and stress corrosion cracking. These Stainless Steel SUS 316 Rectangular Box Sections are mostly used in the pulp and paper industry. It is also used in the marine industry and construction works.

ASME SA554 Steel 316 ERW RHS Pipes, A554 SS 316 Structural Rectangular Hollow Sections, ASTM A554 Gr.316 Stainless Steel Seamless Rectangular Hollow Sections, 316 Stainless Steel Welded Rectangular Tubes Dealers in India.

Specification

Hollow Section Specification

Specifications	ASTM A554 / ASME SA554(Ornamental Tubing Specification) or ASTM A 312
Size	20x20mm to 400x400mm, other non standard sizes available on request
Wall Thickness	0.5mm to 6mm
Length	Up to 6 meters, custom cut lengths
Type	Seamless/ Welded / ERW
Finish	2B, No.1 Pickled Finish, No.4 finish, BA Finish, No.8 Mirror Finish, Electropolished Square Pipes
Delivery Condition	Bright Annealed, Polished or Annealed and Pickled
Packing	In bundles, coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark

Properties

Equivalent Grades
Chemical Composition
Mechanical Properties

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	11.00 – 14.00	67.845 min

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

size and weight

Hollow Section size and weight

Size mm	kg/m	Size mm	kg/m
40 x 20 x 2.0	1.68	40 x 20 x 2.5	2.03
40 x 20 x 3.0	2.36	40 x 25 x 1.5	1.44
40 x 25 x 2.0	1.89	40 x 25 x 2.5	2.23
50 x 25 x 2.0	2.21	50 x 25 x 2.5	2.72
50 x 25 x 3.0	3.22	50 x 30 x 2.5	2.92
50 x 30 x 3.0	3.45	50 x 30 x 4.0	4.46
50 x 40 x 3.0	3.77	60 x 40 x 2.0	2.93
60 x 40 x 2.5	3.71	60 x 40 x 3.0	4.39
60 x 40 x 4.0	5.72	70 x 50 x 2	3.56
70 x 50 x 2.5	4.39	70 x 50 x 3.0	5.19
70 x 50 x 4.0	6.71	80 x 40 x 2.5	4.26
80 x 40 x 3.0	5.34	80 x 40 x 4.0	6.97
80 x 40 x 5.0	8.54	80 x 50 x 3.0	5.66
80 x 50 x 4.0	7.34	90 x 50 x 3.0	6.28
90 x 50 x 3.6	7.46	90 x 50 x 5.0	10.11
100 x 50 x 2.5	5.63	100 x 50 x 3.0	6.75
100 x 50 x 4.0	8.86	100 x 50 x 5.0	10.90
100 x 60 x 3.0	7.22	100 x 60 x 3.6	8.59
100 x 60 x 5.0	11.70	120 x 80 x 2.5	7.65
120 x 80 x 3.0	9.03	120 x 80 x 4.0	12.00
120 x 80 x 5.0	14.80	120 x 80 x 6.0	17.60
120 x 80 x 8.0	22.9	150 x 100 x 5.0	18.70
150 x 100 x 6.0	22.30	150 x 100 x 8.0	29.10
150 x 100 x 10.0	35.70	160 x 80 x 5.0	18.00
160 x 80 x 6.0	21.30	160 x 80 x 8.0	27.90
200 x 100 x 5.0	22.70	200 x 100 x 6.0	27.00
200 x 100 x 8.0	35.4	200 x 100 x 10.0	43.60
250 x 150 x 5.0	30.5	250 x 150 x 6.0	38.2
250 x 150 x 8.0	48.0	250 x 150 x 10	59.3
300 x 200 x 6.0	48.10	300 x 200 x 8.0	60.50
300 x 200 x 10.0	75.00	400 x 200 x 8.0	73.10
400 x 200 x 10.0	90.70	400 x 200 x 16	142.00
